The Stony Path Of Android 🤖 Bug Bounty – Bypassing Certificate Pinning

Dear readers,

Long story short, doing bug bounties for mobile devices is hard. With this article I want to show you a rather simple way to be able to bypass certificate pinning for ~~all~~ some of your Android mobile targets. The method described here is based on research and an awesome blogpost+script written by Piergiovanni Cipolloni. Whenever there was a bypass for certificate pinning it was always involving manipulating the SSLContext of the application. The researcher showed a way to invoke Frida and manipulate the SSLContext to build a script that is able to universally bypass certificate pinning on Android.

In a nutshell the script works like this:

It loads a rogue certificate from the file system (the CA Certificate of Burpsuite);
It creates a very own KeyStore containing our trusted CA;
In a final step it creates a TrustManager that trusts the CA in our KeyStore.

Whenever the application initializes its SSLContex, the Frida script hijacks the “`SSLContext.init()“` method and when it gets called, the 2nd parameter, which is the application TrustManager, with our own TrustManager we previously prepared. On Android the SSLContext function is called as follows: “`SSLContext.init(KeyManager, TrustManager, SecuRandom))“`.

From a beginner’s perspective it is hard to get to the same point as Piergiovanni Cipolloni, therefore this blogpost will include a bit of an introduction to get everything setup properly.

The following blogpost will include:

How to install the Burp certificate to your device;
How to configure Burpsuite for mobile devices;
How to install Frida on your Android device;
How to run a remote Frida Server;
How to install Frida on your server;
How to invoke the script with your application.

Why Certificate Pinning?

With certificate pinning a developer ensures that their application does not accept fake certificates that are actually signed by an official certificate authority. The Android system itself only checks if the hierarchy of the certificate is correct and whether the CA (Certificate Authority) is listed in the so called “certificates of trust store”. But what happens if a malicious person installs a fake CA into the trust store? Well basically that person would be able to intercept the entire HTTPS traffic for the application. For this reason developers go a step further and compile the real certificate in the app and ensure that only this certificate can be used.

Pre-Conditions:

You’d need an Android Virtual Machine (or real device);
Some spare time;
ADB / Android Tools installed + configured.

The Setup – Part 1 Installing the Burp Certificate

With Burpsuite running go to your browser (default: “`127.0.0.1:8080“`) and click on CA Certifcate.

This will download a file called “`cacert.der“`, take the file and rename it to “`cacert.cer“`. If you are wondering what the difference here is, please visit this link: http://www.gtopia.org/blog/2010/02/der-vs-crt-vs-cer-vs-pem-certificates/. The short story is it is just an alternate form.

If you are on a Mac and your default download directory is “`Downloads“` you may do the following:

1.) “`cd /Downloads“` – This changes your directory to Downloads;

2.) “`mv cacert.der cacert.cer“` – This renames the certificate;

3.) “`adb push cacert.cer /mnt/sdcard/DCIM/“` – This copies the certificate to the SD card of your device.

Not too hard right?

On the device itself (whether virtual or real) we have to install the certificate in order to put it into the Android trusted cert store.

To do so:

Click on the Menu Button – Go to “`Settings“` – Scroll all the way down to “`Security“` – Choose “`Install from SD card“`

Tap on the “`cacert.cer“` and name the certificate for example “`Burp“`.

If everything worked you should see under -> “`Settings“` -> “`Security“` -> “`Trusted credentials“` -> “`Users“`, the following entry:

🎉Hurray! 🎉 – You have now installed your own Certificate Authority to your system!

The Setup – Part 2 Configuring Burpsuite

Now that we have installed the PortSwigger (💗) CA on our system we need to setup the proxy in order to intercept the traffic from the application the server.

Setting up your Android Device

Once again go to “`Settings“` -> Click on “`Wi-Fi“` -> Hold and Click “`WiredSSID“` -> Click on “`Modify Network“` -> Click on “`Proxy“` -> Choose “`Manual“`.

You will be presented the following form:

What you need to fill out here:

Proxy Hostname – Is the IP Address of your Burp Suite Application (of your PC, your local IP Address).

Port – Is the Port you have Burp Suite running on (default is 8080).

Setting up Burp

Burp, by default opens a local Proxy running on “`localhost“` Port “`8080“`, in order to intercept our mobile traffic we have to setup Burp to listen on the external IP address. Start Burpsuite and go to “`Proxy“` -> “`Options“` select the current configuration (as shown in the picture below) and click on “`Edit“`.

Now select the option “`Specific Address“` and choose your local IP address (in my case it is 192.168.0.193). For you it can vary depending on how your DHCP server is assigning addresses.

If you are unsure which is your IP address, open up a terminal and type (on OSX) “`ifconfig en0 | grep inet“`.

If you’ve followed this tutorial to this point – 💪 You are now able to intercept traffic through the application without Certificate Pinning 💪! The next chapter will be about bypassing certificate pinning.

The Setup – Part 3 installing Frida on your Android Device

In order to bypass certificate pinning using this method we need to have a copy of “`Frida-Server“` installed on our Android device. To do so, we need the latest version of “`Frida-Server“` which can be downloaded from the Frida releases page on Github: https://github.com/frida/frida/releases, you now will wonder which version you need here…🤔 x86? x86_64? arm? – Thank god there is a command for everything! Just do “`adb shell getprop ro.product.cpu.abi“` to find out the right version for you, in my case it was x86. So for me the right version to choose was “`frida-server-10.6.15-android-x86.xz“`. The experienced reader will notice that the .xz extension is an archive, before we can use the binary we have to extract it first. For the terminal geeks among you just use “`tar -xJf frida-server-10.6.15-android-x86“` for everyone else, the Unarchiver is your best friend. After extracting the binary we once again need to use the terminal.

1. ) mv frida-server-10.6.15-android-x86 frida-server – To rename it to “`frida-server“`;

2.)“`adb root“` – To ensure your environment is capable of running commands as root;

3.) “`adb push frida-server /data/local/tmp/ “` – To copy the “`frida-server“` binary to the device;

4.) “`adb shell “chmod 755 /data/local/tmp/frida-server” “` – To give the binary the correct permission on the file system;

5.) “`adb shell “/data/local/tmp/frida-server &”“` – To run the “`frida-server“` as a service in the background;

5.1) “`adh shell “/data/local/tmp/frida-server –listen 0.0.0.0 &“` if you want to have “`frida-server“` running on an external IP.

Installing Frida on your Machine

🎉🎉Across all platforms, all you need is sudo pip install frida 🎉🎉

To verify your Frida installation (both remote and local) you need to do a “`frida-ps“`. This displays a “`ps“` command that produces a list of the currently running processes on your device.

If connected via USB: “`frida-ps U“`.

If you are using frida on an external address “`frida-ps -H 192.*.*.*“` whatever the address of your phone is.

If you are seeing a similar output:

You are the chosen one, and ready for bypassing certificate pinning.

For the proof of concept I am going to use a random application here, if you want a real-word scenario have a look at the many mobile bug bounties which can be found on Hackerone, Bugcrowd, Synack or Zerocopter.

To start bypassing certificate pinning, we need the Android SSL Re-pinning Frida script by Piergiovanni Cipolloni, which can be found here, here or at the bottom of this blogpost.

Bypassing Certificate Pinning using Frida

First of all, we need to install our target on the device, this can be done in multiple ways:

1.) Install the application from the Google Store.

2.) Download the application using Apkpure or apk-dl.

After doing so, open your terminal and install the application using “`adb install com.company.whatever.apk“`. Done 🐶.

The next step is to choose your target from the applications, as we did before this can be done using: “`frida-ps -H 192.*.*.*“` for a remote Frida server, or “`frida-ps -U“` if you have your device connected via USB. What you need to do next is create a copy of your previously generated “`cacert.cer“` (if you have followed the tutorial until this point it should still be in your “`Downloads“` folder).

For the very last time (I promise!) open up your terminal:

1.) “`cd Downloads“` – Move to the Downloads folder where your “cacert.cer” is;

2.) “`mv cacert.cer burpca-cert-der.crt“` – Rename it to match the file in the Frida Script;

3.) “`wget https://techblog.mediaservice.net/wp-content/uploads/2017/07/frida-android-repinning_sa-1.js“` – Download the Frida script;

4.) “`adb push burpca-cert-der.crt /data/local/tmp/cert-der.crt“` – Push the rogue certificate to the device;

5.) “`frida -U -f it.app.mobile -l frida-android-repinning_sa-1.js –no-pause“` 🎉 NOW FINALLY 🎉 – WE DID IT!

If you see the following output:

It means you did everything right and you can now finally intercept all the traffic from those juicy bug bounty programs out there.

Thank you very much!

Patrik @itsecurityguard

PPS: A big shoutout to

EdOverflow https://twitter.com/EdOverflow for 📚 proofreading 📚

/*
   Android SSL Re-pinning frida script v0.2 030417-pier

   $ adb push burpca-cert-der.crt /data/local/tmp/cert-der.crt
   $ frida -U -f it.app.mobile -l frida-android-repinning.js --no-pause

   Universal Android SSL Pinning bypass with Frida

*/

setTimeout(function(){
    Java.perform(function (){
    	console.log("");
	    console.log("[.] Cert Pinning Bypass/Re-Pinning");

	    var CertificateFactory = Java.use("java.security.cert.CertificateFactory");
	    var FileInputStream = Java.use("java.io.FileInputStream");
	    var BufferedInputStream = Java.use("java.io.BufferedInputStream");
	    var X509Certificate = Java.use("java.security.cert.X509Certificate");
	    var KeyStore = Java.use("java.security.KeyStore");
	    var TrustManagerFactory = Java.use("javax.net.ssl.TrustManagerFactory");
	    var SSLContext = Java.use("javax.net.ssl.SSLContext");

	    // Load CAs from an InputStream
	    console.log("[+] Loading our CA...")
	    cf = CertificateFactory.getInstance("X.509");

	    try {
	    	var fileInputStream = FileInputStream.$new("https://cdn.cybernoz.com/data/local/tmp/cert-der.crt");
	    }
	    catch(err) {
	    	console.log("[o] " + err);
	    }

	    var bufferedInputStream = BufferedInputStream.$new(fileInputStream);
	  	var ca = cf.generateCertificate(bufferedInputStream);
	    bufferedInputStream.close();

		var certInfo = Java.cast(ca, X509Certificate);
	    console.log("[o] Our CA Info: " + certInfo.getSubjectDN());

	    // Create a KeyStore containing our trusted CAs
	    console.log("[+] Creating a KeyStore for our CA...");
	    var keyStoreType = KeyStore.getDefaultType();
	    var keyStore = KeyStore.getInstance(keyStoreType);
	    keyStore.load(null, null);
	    keyStore.setCertificateEntry("ca", ca);

	    // Create a TrustManager that trusts the CAs in our KeyStore
	    console.log("[+] Creating a TrustManager that trusts the CA in our KeyStore...");
	    var tmfAlgorithm = TrustManagerFactory.getDefaultAlgorithm();
	    var tmf = TrustManagerFactory.getInstance(tmfAlgorithm);
	    tmf.init(keyStore);
	    console.log("[+] Our TrustManager is ready...");

	    console.log("[+] Hijacking SSLContext methods now...")
	    console.log("[-] Waiting for the app to invoke SSLContext.init()...")

	   	SSLContext.init.overload("[Ljavax.net.ssl.KeyManager;", "[Ljavax.net.ssl.TrustManager;", "java.security.SecureRandom").implementation = function(a,b,c) {
	   		console.log("[o] App invoked javax.net.ssl.SSLContext.init...");
	   		SSLContext.init.overload("[Ljavax.net.ssl.KeyManager;", "[Ljavax.net.ssl.TrustManager;", "java.security.SecureRandom").call(this, a, tmf.getTrustManagers(), c);
	   		console.log("[+] SSLContext initialized with our custom TrustManager!");
	   	}
    });
},0);
