Google’s FLARE team has released GoStringUngarbler, an open-source tool designed to dismantle string obfuscation in Go binaries protected by the garble compiler.
This innovation addresses growing concerns over malware authors exploiting garble’s advanced literal transformations, which render traditional static analysis ineffective.
The tool combines emulation-driven string extraction with binary patching to produce deobfuscated executables, fundamentally altering reverse engineering workflows for security analysts.
Garble’s Obfuscation Architecture
The garble compiler enhances Go binary protection through AST-level transformations that preserve program semantics while complicating static analysis.
Its -literals flag activates four distinct string encryption methodologies, each requiring specialized decryption approaches.
Stack-Based Transformations
Garble implements three stack manipulation techniques for runtime string decryption:
Simple transformation employs byte-wise arithmetic operations using a randomly generated key and operator (XOR/ADD/SUB). The compiler generates a decryptor function template as shown below:
key := make([]byte, len(data))
obfRand.Read(key)
op := randOperator(obfRand)
for i, b := range key {
data[i] = evalOperator(op, data[i], b)
}This produces assembly patterns where RBX/RCX registers hold decrypted string pointers and lengths before calling runtime_slicebytetostring.
Swap transformation introduces position-dependent encryption through byte pair swapping and dynamic local keys:
for i := len(positions) - 2; i >= 0; i -= 2 {
localKey := byte(i) + byte(positions[i]^positions[i+1]) + shiftKey
data[positions[i]], data[i+1] = evalOperator(op, data[i+1], localKey),
evalOperator(op, data[i], localKey)
}The resulting control flow contains nested loops that shuffle byte order while applying cascading XOR operations1.
Shuffle transformation implements multi-layered obfuscation through permutation matrices and index scrambling:
shuffledIdxs := obfRand.Perm(len(fullData))
for i, b := range fullData {
shuffledFullData[shuffledIdxs[i]] = b
}Analysts face encrypted data fragments interleaved with decryption keys across randomized memory regions.
Seed Transformation Mechanics
This chain-based approach creates cryptographic dependencies between bytes using evolving seed values:
seed := byte(obfRand.Uint32())
for i, b := range data {
encB := evalOperator(op, b, seed)
seed += encB
}Decompiled code reveals successive CALL instructions that sequentially update the seed through arithmetic operations.
Split Transformation Infrastructure
Garble partitions strings into chunked ciphertexts managed through state machines:
switchCases := []ast.Stmt{&ast.CaseClause{
List: []ast.Expr{ah.IntLit(decryptIndex)},
Body: shuffleStmts(obfRand,
&ast.AssignStmt{
Lhs: []ast.Expr{ast.NewIdent("i")},
Tok: token.ASSIGN,
Rhs: []ast.Expr{ah.IntLit(exitIndex)},
},
decryptLogic)}}Control flow jumps between randomized SWITCH cases to reassemble encrypted payloads.
GoStringUngarbler’s Deobfuscation Pipeline
The tool implements a three-stage process combining pattern recognition, emulation, and binary modification:
1. Subroutine Identification
Regular expressions target garble’s assembly fingerprints preceding runtime_slicebytetostring calls:
48 8D 5C ?? ?? lea rbx, [rsp+]
B9 ?? ?? ?? ?? mov ecx,
E8 ?? ?? ?? ?? call runtime_slicebytetostring YARA rules classify transformation types based on register initialization patterns.
2. Emulation Engine
Unicorn-based emulation executes decryptors from identified prologues:
49 3B ?? ?? cmp rsp, [+]
76 ?? jbe short Memory snapshots capture decrypted strings post-emulation without executing malware payloads.
3. Binary Patching
Original decryptors undergo surgical replacement with static string loads:
xor eax, eax
lea rbx, 0x5FFD00 ; Decrypted string address
mov ecx, 0x1A ; String length
call runtime_slicebytetostring
retThe remaining function space gets padded with INT3 breakpoints to prevent execution artifacts.
Implications for Malware Analysis
GoStringUngarbler introduces paradigm shifts in three key areas:
- Automated TTP Extraction: Over 92% of garble-obfuscated strings in tested samples were successfully recovered, enabling faster IOC generation.
- Cross-Platform Analysis: Python implementation allows integration with disassemblers like Ghidra and Binary Ninja without vendor lock-in.
- Proactive Defense: Open-source availability (Mandiant GitHub) lets EDR vendors incorporate deobfuscation into scanning pipelines pre-execution.
Google’s breakthrough demonstrates that garble’s protections—while sophisticated—are not insurmountable.
By combining instruction pattern analysis with emulation and surgical binary editing, GoStringUngarbler delivers practical countermeasures against evolving Go malware threats.
Security teams should integrate this tool into reverse engineering workflows to neutralize obfuscation advantages currently exploited by adversaries.
