In a recent exploration of embedded device hacking, a researcher demonstrated how to extract firmware from flash memory using the flashrom tool.
This process is crucial for understanding device operation and identifying potential vulnerabilities.
However, it involves risks that can damage the equipment if not executed carefully.
The Importance of Firmware Extraction
Firmware is essential for analyzing how devices operate and identifying potential vulnerabilities.
It can be obtained through various methods, including downloading from official websites, sniffing firmware update packets, or using debugging ports like UART and JTAG.
Directly extracting firmware from flash memory is considered more reliable but poses significant risks, such as damaging the board or chip during the process.
According to Hackyboiz Report, this method involves removing the flash memory chip from the device, which requires caution to avoid damaging the board.
The Flashrom Method
To perform a flash memory dump, researchers use a Raspberry Pi with flashrom installed.
The process involves several steps:
- Installing flashrom: This requires setting up the Raspberry Pi in 64-bit mode and installing necessary dependencies before compiling and installing flashrom from its GitHub repository.
- Removing the Flash Memory Chip: A heat gun is used to desolder the chip from the board. This step is risky and requires precision to avoid damaging the board.
- Connecting the Chip to Raspberry Pi: The chip is connected to the Raspberry Pi using an IC Test Hook Clip and jumper cables. The connection involves matching the chip’s pins (VCC, GND, SCLK, CS, DI, DO, WP, and Hold) to the appropriate GPIO pins on the Raspberry Pi.
- Dumping the Firmware: Once connected, flashrom is used to detect and read the chip, and the firmware is extracted using specific commands. If the chip is not supported, modifications to flashrom’s source code may be necessary.
The process of removing and reconnecting the flash memory chip poses significant risks, including short circuits and damage to the board or chip.
Therefore, it is advisable to attempt other methods of firmware extraction before resorting to this approach.
Despite these risks, successful extraction allows for a deeper understanding of the device’s operation and potential vulnerabilities, making it a valuable tool in embedded device hacking.
After extraction, reassembling the device by resoldering the chip can restore its functionality.
